Product Summary

Model: LQ9P341
Display Type: a-Si TFT-LCD
Operating Temperature:0-50
Size:8.4 inch
Aspect Ratio: 4:3(W:H)
Dot Pixels: 640(RGB)*480(VGA)
Pixel Configuration: RGB Vertical Stripe
Pixel Pitch:0.267*0.270 mm(W*H)
Surface:Clear, Hard coating(2H)
Active area: 170.88*129.6 mm(W*H)
Bezel area: 177.5*134.2 mm(W*H)
Outline Dimension: 242.5*179.4 mm(W*H)
Outline Depth: 7.5(Typ.)mm
Holes&Brackets: Face mounting holes
Viewing Area: 35/35/30/10(min.)(CR≥10)(L/R/U/D)
Response time: 20/40(Typ.)(Tr/Td)(ms)
Display color: 262K(6-bit)
Contrast Ratio: 130:1(Min)(Transmissive)
Display Mode: TN,Normally White,Transmissive
