Product Summary

The XTR115 and XTR116 are precision current output
converters designed to transmit analog 4-to-20mA
signals over an industry standard current loop. They
provide accurate current scaling and output current
limit functions.
The on-chip voltage regulator (5V) can be used to
power external circuitry. A precision on-chip VREF
(2.5V for XTR115 and 4.096V for XTR116) can be

used for offsetting or to excite transducers. A current
return pin (IRET) senses any current used in external
circuitry to assure an accurate control of the output
current.
The XTR115 is a fundamental building block of
smart sensors using 4-to-20mA current transmission.
The XTR115 and XTR116 are specified for operation
over the extended industrial temperature range,
–40°C to +85°C.



Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XTR115UA
XTR115UA

Texas Instruments

Current Sense Amplifiers 4-20mA Current Loop Transmitters

Data Sheet

0-1: $2.02
1-10: $1.82
10-25: $1.62
25-50: $1.52
XTR115UA/2K5
XTR115UA/2K5

Texas Instruments

Current Sense Amplifiers 4-20mA Current Loop Transmitters

Data Sheet

0-2010: $0.84
2010-2500: $0.84
XTR115UAE4
XTR115UAE4

Texas Instruments

Current Sense Amplifiers 4-20mA Current Loop Transmitters

Data Sheet

0-1: $2.02
1-10: $1.82
10-25: $1.62
25-50: $1.52
XTR115UA/2K5E4
XTR115UA/2K5E4

Texas Instruments

Current Sense Amplifiers 4-20mA Current Loop Transmitters

Data Sheet

0-2010: $0.84
2010-2500: $0.84
