Product Summary

Designed for wideband large–signal amplifier and oscillator applications to
500 MHz.
? Guaranteed 28 Volt, 400 MHz Performance
Output Power = 2.0 Watts
Minimum Gain = 16 dB
Efficiency = 55% (Typical)
? Grounded Source Package for High Gain and Excellent Heat
Dissipation (MRF158R)
? Facilitates Manual Gain Control, ALC and Modulation
Techniques
? 100% Tested for Load Mismatch at All Phase Angles with
30:1 VSWR
? Excellent Thermal Stability, Ideally Suited for Class A
Operation
? Circuit board photomaster available upon request by
contacting RF Tactical Marketing in Phoenix, AZ.
