Product Summary

Designed primarily for linear large–signal output stages up to 150 MHz
frequency range.
? Specified 50 Volts, 30 MHz Characteristics
Output Power = 150 Watts
Power Gain = 17 dB (Typ)
Efficiency = 45% (Typ)
? Superior High Order IMD
? IMD(d3) (150 W PEP) — –32 dB (Typ)
? IMD(d11) (150 W PEP) — –60 dB (Typ)
? 100% Tested For Load Mismatch At All Phase Angles With
30:1 VSWR
