Product Summary
Features
? Excellent Noise Figure: 2.0 dB
? Gain: 22 dB
? P1dB Output Power: +11 dBm
? Supply Voltage: +5V @ 66 mA
? Die Size: 2.10 x 1.37 x 0.1 mm
Typical Applications
? Point-to-Point Radios
? Point-to-Multi-Point Radios
? Phased Arrays
? VSAT
? SATCOM
Functional Diagram
General Description
The HMC-ALH369 is a GaAs MMIC HEMT three stage, self-biased Low Noise Amplifier die which operates between 24 and 40 GHz. The amplifier provides 22 dB of gain, from a single bias supply of +5V @ 66 mA with a noise figure of 2 dB. The HMC-ALH369 amplifier die is ideal for integration into Multi-Chip-Modules (MCMs) due to its small size (2.88 mm2).
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 HMC-ALH369 |
Other |
|
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
HMC-ABH209 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
HMC-ABH241 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
HMC-ALH102 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
HMC-ALH140 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
HMC-ALH216 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
HMC-ALH244 |
Other |
|
Data Sheet |
Negotiable |
|
||||
